Product Details:
|
| Material: | Metallized Polyester Film | Applications: | Lighting |
|---|---|---|---|
| Capacitance Range: | 0.001mf~3.3uf | Type: | Polyester Film Capacitor |
| Printing: | Oil Printing / Laser Printing | Color: | Red |
| Highlight: | 154J Metallized Polyester Film Capacitor,100V Metallized Polyester Film Capacitor,154J Capacitor |
||
154j 100v Metallized Polyester Film Capacitor Self-Healing , High Temperature
Product Fetures:
This product is ultra-small, self-healing, high temperature, the small capacity available in series production of metallized film, high pressure, high temperature wax seal, flame retardant epoxy powder coating, moisture stable performance, low noise, appearance consistency.
Usage:
Suitable for DC and lowpulse occasions, forthe amplifier, TV, communications, power supply, LED drivers and other requirements of the small size of the circuit.
Specification:
| Climatic Category | 40/085/21 |
| Rated Voltage | 63V , 100V , 250V,400V,630V |
| Capacitance Range | 0.0010μF~1.0μF |
| Voltage Proof | 1.6 UR |
| Insulation Resistance | ≥3 000MΩ, CR≤0.33μF |
| ≥1 000S, CR>0.33μF | |
| (20℃, 1min) | |
| Disspation Factor | ≤0.008(20℃, 1kHz) |
Outline Drawing:
FAQ
Q;Materials of products?
A;A metallized film for A + grade capacitors. Besides we accept customization
Q;Samples are free?
A:yes!
Q;Quality Control?
A;Quality is first,We has passed ISO9001and ROHS REACH certification,As an important part of quality management, quality control is the key to proving the effectiveness of quality certification.
