| Dissipation Factor: | 0.5mW/°C To 10mW/°C | Termination Style: | Axial Leads, Radial Leads, SMD Pads |
|---|---|---|---|
| Output: | Analog Sensor | Sample: | Available |
| Resistance Range: | 1Ω To 100MΩ | Keyword: | NTC Thermal Resistor |
| Customize: | Provide Sample Services | Thermal Time Constant: | 1s To 15s |
| Highlight: | 1.5D11 ntc thermal resistor,1.5D-15 ntc thermal resistor,SMD ntc thermal resistor |
||
Our NTC Thermal Resistor is designed to operate in extreme temperatures, with an operating temperature range of -40℃~150℃. This makes it ideal for use in a variety of industries, including automotive, aerospace, and industrial manufacturing.
Our product is available for sampling, allowing you to test and evaluate its performance in your specific application.
Whether you're looking for a thermally activated resistor for temperature sensing or control, our NTC Thermal Resistor is the perfect choice. It is also known as an NTC Thermal Probe, Thermally Activated Resistor, or Thermally Sensitive Resistor.
| Technical Parameter | Description |
|---|---|
| Part No | 22D-9 |
| Termination Style | Axial Leads, Radial Leads, SMD Pads |
| Dissipation Factor | 0.5mW/°C To 10mW/°C |
| Lead Material | Tinned Copper, Nickel, Silver |
| Usage | Temperature Sensor |
| Mounting Type | Through Hole, Surface Mount |
| Operating Temperature | -40℃~150℃ |
| Sample | Available |
| Resistance Range | 1Ω To 100MΩ |
| Thermal Coefficient | -2% To -6% |
The CL 5D9-D13-D15-D20 is available with three different termination styles: axial leads, radial leads, and SMD pads. The lead material options include tinned copper, nickel, and silver, providing a range of choices to suit your specific needs. With a dissipation factor that ranges from 0.5mW/°C to 10mW/°C, this product is perfect for applications where precision and accuracy are key.
The CL 5D9-D13-D15-D20 thermal resistor is an excellent choice for a wide range of product application occasions and scenarios. It is commonly used in temperature measurement, temperature compensation, and temperature control circuits. This makes it an ideal choice for use in a variety of industries such as automotive, telecommunications, aerospace, and medical devices.
One scenario where the CL 5D9-D13-D15-D20 thermal resistor excels is in temperature measurement applications. Its high accuracy and precision make it perfect for use in temperature sensing devices. It can be used in temperature probes, thermostats, and temperature controllers, among other applications.
Another scenario where the CL 5D9-D13-D15-D20 thermal resistor is useful is in temperature compensation applications. Its high thermal sensitivity makes it an excellent choice for use in compensation circuits used in thermocouples and other temperature sensors.
The CL 5D9-D13-D15-D20 thermal resistor is also commonly used in temperature control circuits. This makes it an ideal choice for use in ovens, refrigerators, and other temperature-controlled environments. Its fast thermal response time and high accuracy make it a reliable choice for these types of applications.
Overall, the CL 5D9-D13-D15-D20 thermal resistor is a versatile and high-quality product that is perfect for many product application occasions and scenarios. With its high thermal sensitivity, accuracy, and precision, it is an ideal choice for use in temperature measurement, temperature compensation, and temperature control circuits. With a sample available, it's easy to test and see if this product is the right choice for your specific needs.
The NTC Thermal Resistor product technical support and services include:
Our team of experienced professionals is dedicated to providing superior customer service and support to ensure the optimal performance and reliability of our NTC Thermal Resistor products.
Q: What is the brand name of this NTC Thermal Resistor?
A: The brand name of this NTC Thermal Resistor is CL.
Q: What are the model numbers available for this NTC Thermal Resistor?
A: The model numbers available for this NTC Thermal Resistor are 5D9, D13, D15, and D20.
Q: Where is this NTC Thermal Resistor manufactured?
A: This NTC Thermal Resistor is manufactured in China.
Q: What is the temperature range for this NTC Thermal Resistor?
A: The temperature range for this NTC Thermal Resistor is -40°C to 125°C.
Q: What is the resistance tolerance for this NTC Thermal Resistor?
A: The resistance tolerance for this NTC Thermal Resistor is ±5%.
