FMIDI® Compact In Line Fuse Holder 500 Amp

FMIDI® Compact In Line Fuse Holder 500 Amp
FMIDI® Compact In Line Fuse Holder 500 Amp FMIDI® Compact In Line Fuse Holder 500 Amp FMIDI® Compact In Line Fuse Holder 500 Amp

Large Image :  FMIDI® Compact In Line Fuse Holder 500 Amp

Product Details:
Place of Origin: CHIANA
Brand Name: littelfuse
Certification: E71747
Model Number: MAGE
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: 3USD
Packaging Details: 200x200x200cm
Payment Terms: T/T
Supply Ability: 300000
Contact Now

FMIDI® Compact In Line Fuse Holder 500 Amp

Description
Highlight:

FMIDI® Fuse Holder

,

In Line Fuse Holder

,

Compact Fuse Holder

MIDI® Compact In-line Fuse Holder


FMIDI® Compact In Line Fuse Holder 500 Amp 0

Description

Specifications
Agency Approval Shock: VS-005002/VS-005005
Current Rating Max: 500A
Fuse Type: MEGA (298)
Humidity: 97%±3% relative humidity
at 40°C±3C for 16 hrs
Flammibility Rating: UL-94 V-2
Ingress Protection: Dust Protection
Input Terminals: M8 Stud, M6 Stud
Mounting Method: Bolt-Down, M6 Slots / M6 Mounting Holes
Output Terminals: M8 Stud, M6 Stud
Recommended Torque: 8mm Hex Nut: 12-18 Nm (106-159 IN-LBS)
6mm Hex Nut: 8-14 Nm (71-124 IN-LBS)
Max Voltage Rating: 70VDC
Features & Benefits
Designed for use with bolt-down MIDI style fuses. It can be conveniently installed directly in-line with
the cables and no mounting required. The fuse holder is easy to shrinkwrap for environmental
protection and the corners of the cover are curved so that shrinkwrap will not be split.






Tag:

High Current Fuse Holder,

M6 Slots Fuse Holder,

Bolt Down Fuse Holder
