Product Details:
|
| Termination Style: | Axial | Voltage Characteristics: | High Voltage |
|---|---|---|---|
| Lead Diameter: | 1.5mm | Shape: | Coaxial,DO-35 |
| Agency Recognition: | UL | Operating Temp: | -40~+85C |
| Impulse Voltage: | ≤1100V | Relative Humidity: | ≤75%RH |
| Highlight: | Coaxial Shape Gas Discharge Tube,UL Recognized Gas Discharge Tube,Axial Gas Discharge Tube |
||
The Gas Discharge Tube is a cutting-edge solution designed to protect sensitive electronic equipment from transient overvoltage conditions, commonly caused by lightning strikes, electrostatic discharge, and other electrical anomalies. This state-of-the-art component is an essential addition to any electronic system that requires reliable overvoltage protection to ensure longevity and uninterrupted performance.
At the core of this Gas Discharge Tube's design is its configuration with 2 electrodes, which facilitates the creation of a controlled electrical discharge path. This effectively channels the excess voltage away from the protected circuit, thus preventing potential damage. The Gas-Filled Discharge Tube operates by ionizing the gas contained within the tube, which becomes conductive and allows the excess energy to be safely diverted.
This Gas Discharge Tube boasts a compact size of φ8*10mm, allowing it to be easily integrated into a variety of electronic assemblies without occupying excessive space. The small footprint of this component makes it particularly suitable for high-density circuit designs where space is at a premium. Despite its diminutive size, it offers robust protection, making it a preferred choice for designers seeking to minimize the impact on their overall system layout without compromising on safety.
One of the key features of this Gas-Filled Discharge Tube is its exceptionally low electrode capacitance of less than 1 picofarad (<1PF). This low capacitance ensures that the tube has minimal impact on the normal operation of the circuit, maintaining signal integrity and preventing any significant attenuation or distortion of high-frequency signals. It is especially critical for applications that rely on the precise transmission of data, such as high-speed communication lines and sensitive measurement equipment.
The Gas Discharge Tube is equipped with robust leads, each having a diameter of 1.5mm. These leads are engineered to offer a secure and reliable connection to the circuit board, ensuring that the Gas-Filled Discharge Tube remains firmly in place even in the face of mechanical vibrations or thermal expansion. The leads' substantial diameter also contributes to the device's overall current-carrying capability, allowing it to handle the instantaneous high current associated with discharge events.
Designed to operate effectively in a wide range of environmental conditions, this Gas Discharge Tube can maintain its protective performance with a relative humidity of up to 75%RH. This level of humidity resilience makes the component suitable for deployment in environments where moisture levels can fluctuate, such as in outdoor applications or regions with variable climates. The ability to withstand these conditions without degradation ensures that the Gas-Filled Discharge Tube remains a reliable safeguard against voltage transients throughout its service life.
In summary, the Gas Discharge Tube is an indispensable component that offers superior overvoltage protection for electronic systems. With its 2-electrode configuration, compact size, low electrode capacitance, sturdy 1.5mm lead diameter, and high relative humidity tolerance, it epitomizes the ideal balance between performance and practicality. Whether employed in telecommunications, industrial controls, or consumer electronics, this Gas-Filled Discharge Tube stands as a bulwark against the potentially devastating effects of electrical surges, thus preserving the integrity and performance of vulnerable electronic circuits.
| Parameter | Value |
|---|---|
| Size | φ8*10mm |
| Relative Humidity | ≤75%RH |
| Voltage Rating | Up To 1000V |
| Voltage Characteristics | High Voltage |
| Shape | Coaxial, DO-35 |
| Protection | With Failsafe |
| Termination Style | Axial |
| Operating Temp | -40~+85C |
| Electrode Capacitance | <1PF |
| Agency Recognition | UL |
The CL brand Gas Discharge Tube, originating from CHINA, is a state-of-the-art protective device designed to ensure the safety and reliability of electronic equipment. This Gas-Filled Discharge Tube stands out for its robust construction, incorporating a compact size of φ8*10mm, and a coaxial, DO-35 shape that makes it suitable for a variety of applications. With an operating temperature range of -40~+85°C, these tubes are built to withstand extreme environmental conditions, ensuring consistent performance across a wide range of temperatures.
Boasting a high voltage rating of up to 1000V, the CL Gas Discharge Tube is a versatile component that can be applied in numerous scenarios where voltage spikes are a concern. It is particularly useful in scenarios where equipment is exposed to transient overvoltage events, such as lightning strikes or electrical surges. Its ability to handle an impulse discharge current of 2KA signifies that it can provide effective protection against substantial surges, safeguarding sensitive circuits from damage.
The Cold-Cathode Gas Discharge Tube from CL is ideally suited for telecommunications equipment, where it can protect against surges induced by switching operations or other disruptions. It's also a critical component in power supply units and surge protection devices, where its rapid response to overvoltage events helps prevent the failure of connected devices. In industrial settings, the Gas-Filled Discharge Tube is essential for safeguarding control systems and sensors, which are crucial for maintaining operational efficiency and safety.
Consumer electronics also benefit from the incorporation of the CL Gas Discharge Tube, particularly in high-definition television sets, satellite systems, and home theater installations, where it ensures the longevity of the equipment by preventing damage due to electrical surges. In the realm of networking, the Gas-Filled Discharge Tube provides indispensable protection for network interfaces and communication lines, which are often vulnerable to voltage spikes caused by electromagnetic interference or other forms of disruption.
In summary, the CL brand Gas Discharge Tube is a highly reliable and efficient solution for a wide range of applications that require protection against voltage transients. Its robust design, considerable voltage rating, and substantial discharge current handling capability make it a key component for securing the integrity of electronic systems across various industries and in consumer products.
Brand Name: CL
Place of Origin: CHINA
Protection: With Failsafe
Size: φ8*10mm
Shape: Coaxial, DO-35
Impulse Discharge Current: 2KA
Lead Diameter: 1.5mm
Our CL Gas Discharge Tube offers reliable surge protection in a compact φ8*10mm size. This Gas-Discharge Tubular Lamp is designed with a coaxial, DO-35 shape and an impulse discharge current rating of 2KA, making it suitable for a range of applications. The 1.5mm lead diameter ensures a sturdy connection, while the integral failsafe feature provides an additional layer of security. Manufactured in CHINA, this Gas Discharge Lighting Tube is an essential component for safeguarding sensitive electronics against voltage transients.
The Gas Discharge Tube (GDT) product line is designed to provide high-quality surge protection solutions for a variety of applications. Our GDTs are rigorously tested to ensure they meet industry standards for performance and reliability. To help you get the most out of our products, we offer comprehensive technical support and services.
Product Technical Support includes:
Our Services include:
We are committed to providing exceptional support and services to our customers. If you have any questions or need further assistance with our Gas Discharge Tube products, please reach out to our technical support team.
Product Packaging for Gas Discharge Tube:
Each Gas Discharge Tube is individually packed in an anti-static bag to prevent any potential damage from electrostatic discharges. The anti-static bag is then placed within a cushioned box to provide additional protection against physical shocks during handling. The boxes are labeled with the product information, handling instructions, and a barcode for easy inventory management.
Shipping Information for Gas Discharge Tube:
The cushioned boxes are further packed into a sturdy, corrugated cardboard box for shipping. The cardboard box is sealed with heavy-duty tape and clearly marked with "Fragile - Handle with Care" to ensure the safe transport of the product. The package is accompanied by a packing slip that details the contents and includes the order number for reference. The shipping method is chosen based on the customer's preference, with options ranging from standard to expedited delivery services.
Q1: What is a Gas Discharge Tube (GDT) and how does it work?
A1: A Gas Discharge Tube is a device that helps protect electronic equipment from over-voltage transients by providing a conduction path to ground when a certain voltage threshold is exceeded. It contains an inert gas that ionizes and conducts electricity when the voltage across the GDT terminals reaches a specified level, thus diverting the excess energy away from sensitive components.
Q2: Can the CL brand Gas Discharge Tube be used for both AC and DC applications?
A2: Yes, the CL Gas Discharge Tubes are designed to handle transient over-voltage conditions for both AC and DC applications, making them versatile for various types of electrical circuits.
Q3: What is the anticipated lifespan of a CL Gas Discharge Tube?
A3: The lifespan of a CL Gas Discharge Tube can vary depending on its usage conditions, such as the frequency of transient events and the magnitude of surges it has to mitigate. Under normal operation conditions, GDTs can last for many years without needing replacement.
Q4: Are CL Gas Discharge Tubes suitable for outdoor use?
A4: Yes, CL Gas Discharge Tubes are built to withstand various environmental conditions, making them suitable for outdoor applications. However, it's essential to ensure they are housed in appropriate enclosures to protect them from direct exposure to harsh weather conditions.
Q5: How do I select the appropriate CL Gas Discharge Tube for my application?
A5: To select the right CL Gas Discharge Tube, you need to consider the maximum operating voltage of your system, the anticipated surge current levels, and the specific application requirements. It's recommended to consult the datasheet for the GDT series to match these parameters with the device specifications. Additionally, you may contact CL technical support for further assistance in selecting the correct GDT for your needs.
